HP ProBook 5220m - Notebook PC

7. Disconnect the display panel cable (1) from the system board.
8. Disconnect the power button ZIF cable (2) from the system board.
9. Remove the two PM2.5×5.0 screws that secure the system board to the base enclosure.
10. Lift the right side of the system board from the base enclosure (1).
Component replacement procedures 73
