HP ProBook 6455b User Manual

For use in country or region: Spare part
number
For use in country or region: Spare part number
For use in Hungary 613384-211 For use in Switzerland 613384-BG1
For use in Iceland 613384-DD1 For use in Taiwan 613384-AB1
For use in Israel 613384-BB1 For use in Thailand 613384-281
For use in Italy 613384-061 For use in Turkey 613384-141
For use in Japan 613384-291 For use in the United Kingdom 613384-031
For use in Latin America 613384-161 For use in the United States 613384-001
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 79).
Remove the keyboard:
1.
Position the computer with the front toward you.
2. Loosen the three Phillips PM2.5×11.0 captive screws that secure the keyboard to the computer.
3. Turn the computer right-side up, with the front toward you.
4. Open the computer as far as it will open.
5. Slide the four keyboard tabs (1) forward.
98 Chapter 4 Removal and replacement procedures

HP ProBook 6455b Specifications

General

Graphics	ATI Mobility Radeon HD 4250
Chipset	AMD M880G
Processor	AMD Phenom II
Display	14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768)
Memory	Up to 8 GB DDR3
Storage	128 GB Solid State Drive
Optical Drive	DVD+/-RW SuperMulti DL
Ports	3 USB 2.0
Battery	6-cell lithium-ion
Operating System	Windows 7 Professional
Wireless	Bluetooth
Audio	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in
Card Reader	5-in-1 card reader
Webcam	2 MP Webcam
