HP ProBook 6570b User Manual

HP ProBook 6570b
HP recommends Windows
®
7.
SPECIFICATIONS
Operating system
Preinstalled:
Genuine Windows® 7 Professional 32
7
Genuine Windows 7 Professional 64
7
Genuine Windows 7 Home Premium 64
7
SUSE Linux Enterprise Desktop 11
FreeDOS
Supported:
Genuine Windows 7 Enterprise 32
7
Genuine Windows 7 Enterprise 64
7
Genuine Windows 7 Ultimate 32
7
Genuine Windows 7 Ultimate 64
7
Genuine Windows XP Professional 32
8
Genuine Windows Home Basic 64
8
Certified:
SUSE Linux Enterprise Desktop 11
Processor
3
rd
Generation Intel® Core™ i7 and i5 Dual-Core
2
with Turbo Boost Technology;
9
2
nd
Generation Intel® Core™ i3 Dual-Core
2
Chipset
Mobile Intel® QM77 Express Chipset (vPro
10
configurations)
Mobile Intel® HM76 Express Chipset (non-vPro
10
configurations)
Memory
DDR3 PC3-12800 SDRAM, 1600 MHz, two slots supporting dual-channel memory, 2/4/8 GB SODIMMs, up to 16 GB total
8
Internal Storage
12
320/500 GB 7200 rpm HDD, 500 GB 7200 rpm SED (Self Encrypting Drive) HDD, SATA 6 Gb/s 128 GB SSD, 256 GB SSD SED;
HP 3D DriveGuard
5
Upgrade Bay
12.7 mm SATA optical drive: Blu-ray
27
ROM DVD+/-RW SuperMulti DL Drive,
1,23,25
DVD+/-RW SuperMulti DL Drive,
1,23,25
DVD-ROM Drive; 500 GB 7200 rpm
1
secondary HDD; or weight saver
Display
15.6“ diagonal LED-backlit HD
3
anti-glare (1366 x 768), 15.6“ diagonal LED-backlit HD+
3
WVA anti-glare (1600 x 900)
Graphics
Integrated: Intel® HD
3
Graphics 4000 (3
nd
Generation Core™ processors); Intel® HD
3
Graphics 3000 (2
nd
Generation Core™
processors).
Discrete: AMD Radeon
TM
HD
3
7570M, with 1 GB dedicated GDDR5 video memory
Audio/Visual
High Definition Audio with SRS Premium Sound, stereo speakers, optional 720p HD
3
Webcam,
1,16
integrated microphone
or dual-microphone array with optional webcam
Wireless Support
1,15,16
HP hs2350 HSPA+ Mobile Broadband; HP un2430 EV-DO/HSDPA+ Mobile Broadband (Gobi
TM
3000); Intel® Centrino®
Advanced-N 6205 802.11a/b/g/n 2x2; Intel® Centrino® Wireless-N 2200 802.11 b/g/n 2x2; 802.11 a/b/g/n 2x2; 802.11
b/g/n 1x1; HP Integrated Module with Bluetooth® v4.0 + EDR Wireless Technology; HP Connection Manager
Communications
Intel® 879LM Gigabit Network Connection (QM77), Intel® 879V Gigabit Network Connection (HM76), 56K v.92 modem
(optional)
Ports and Connectors
2 USB 3.0 ports, 2 USB 2.0 ports, 1 eSATA/USB 2.0 combo port, 1 VGA port, 1 DisplayPort (UMA v1.1a; discrete v1.2),
1 stereo microphone port, 1 stereo headphone port; 1 serial port; 1 1394a port, 1 RJ-11 (optional modem) port,
1 RJ-45 (Ethernet) port, 1 docking connector, 1 secondary battery connector, 1 power connector
Expansion Slots
1 ExpressCard/54 slot, 1 SD/MMC slot
Input Devices
Full-sized spill-resistant keyboard with bottom case drain, separate numeric keypad, touchpad with scroll zone and
gestures support, optional point stick,
1
4 discrete buttons (Web browser, WLAN on/off, mute, and calculator)
Software
(Windows OS only)
HP Power Assistant,
6
HP Recovery Manager, HP Support Assistant, Adobe® Flash Player, Corel WinDVD (select models),
Roxio Secure Burn
23
(select models), Roxio MyDVD Business 2010 (select models), Skype,
16
PDF Complete Corporate
Edition, WinZip Basic, Microsoft® Office Starter: reduced-functionality Word and Excel only, with advertising, no
PowerPoint or Outlook. Buy Office 2010 to use the full-featured software.
17
Custom Integration Services provides tailor-made, turnkey solutions for Business Ready PCs.
Security
Standard: Microsoft Security Essentials, HP ProtectTools,
5
Central Management for HP ProtectTools,
24
TPM Embedded
Security Chip 1.2, Pre-Boot Security, HP SpareKey (requires initial user setup), HP Disk Sanitizer,
18
Drive Encryption for
HP ProtectTools, Credential Manager for HP ProtectTools, Face Recognition for HP ProtectTools,
22
File Sanitizer for
HP ProtectTools,
18
security lock slot.
Optional: Computrace anti-theft software,
19,21
Intel® Anti-Theft Technology (requires a Computrace subscription),
19,21
HP
Fingerprint Sensor, Smart Card Reader (replaces ExpressCard), HP Privacy Filter
Dimensions (w x d x h)
14.72 x 9.86 x 1.35 in (at front) / 37.4 x .1 x3.4 cm (at front)
Weight
Starting at 5.53 lb (2.51 kg) without optical drive; 5.76 lb (2.62 kg) with DVD-ROM drive (weight will vary by configuration)
Power
4
Primary: 9-cell (100 WHr) Lithium-Ion battery, 6-cell (55 WHr) Lithium-Ion battery, 6-cell (55 WHr) HP Long Life Battery,
Secondary: optional HP ST09 Extended Life Notebook Battery (9-cell /73 WHr), optional HP BB09 Ultra Extended Life
Notebook Battery (9-cell /100 WHr); 90W HP Smart AC Adapter (discrete graphics) or 65W HP Smart AC Adapter
(integrated graphics); HP Fast Charge
20
Expansion Solutions
1
HP 90W Docking Station, HP 120W Advanced Docking Station, HP USB 2.0 Port Replicator, HP USB 3.0 Port Replicator,
HP Dual Hinge Notebook Stand, HP Display and Notebook Stand, HP Adjustable Dual Display Stand
Warranty
Limited 3-year, 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on primary
battery; 3-year limited warranty on HP Long Life Battery (only available with 3-year platform warranty). Optional HP Care
Pack Services
11
are extended service contracts which go beyond your standard warranties. For more details visit:
hp.com/go/lookuptool.

HP ProBook 6570b Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	90 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-3110M
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-3100 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	24
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM76 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
LightScribe	-
Intel segment tagging	Enterprise
Ethernet interface type	Gigabit Ethernet
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product color	Black
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	7.25 h
Number of battery cells	6
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Processor code	SR0N2
Processor ARK ID	65700
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	251 mm
Width	374 mm
Height	34 mm
Weight	2510 g
