5-63
Quality of Service: Managing Bandwidth More Effectively
Globally-Configured QoS
Example. This example shows how to prioritize inbound traffic on the
following source-ports:
Enter the following commands to prioritize packets received from the speci-
fied source ports:
Figure 5-28. Configuring and Displaying Source-Port QoS Priorities
If you later decided to remove source-port A1 from QoS prioritization, you
would enter the following command:
Syntax: no interface < port-list > qos
Disables use of the specified source-port(s) for QoS classi-
fier(s) and resets the priority for the specified source-port(s)
to No-override.
Syntax: show qos port-priority
Lists the QoS port-priority classifiers with their priority
data.
Source-Port Priority
A1 - A3 2
A4 3
B1, B4 5
C1-C3 6
HP Switch(config)# interface 1-3 qos priority 6
HP Switch(config)# interface 4-5 qos priority 5
HP Switch(config)# interface 6-7 qos priority 3
Switch(config)# show qos port-priority
Port priorities
Port Apply rule | DSCP Priority Radius Override
---- ----------- + ------ ----------- ---------------
1 Priority | 6 No-override
2 Priority | 6 No-override
3 Priority | 6 No-override
4 Priority | 5 No-override
5 Priority | 5 No-override
6 Priority | 3 No-override
7 Priority | 3 No-override
8 No-override | No-override No-override
9 No-override | No-override No-override
10 No-override | No-override No-override
