Rear panel components
Figure 92 Rear Panel Components
Item Description
1 Power supply cable socket
2 SD card reader port (optional)
3 Rear UID LED/switch
4 Mgmt port (optional)
5 Serial port
6 GbE LAN port for NIC 4
7 Full-height/full-length PCI expansion card slot cover
8 T-10/T-15 wrench
9 Screw for PCI cage
10 GbE LAN port for NIC 1
11 GbE LAN port for NIC 2
12 VGA port
13 GbE LAN port for NIC 3
14 Rear panel USB 2.0 port 0/1
