HP ProLiant DL320e Gen8 - Page 21

Illustrated parts catalog 21
Item Description Spare part
number
Customer self repair (on
page
6
)
c) 1 TB, 6G hard drive*
653947-001
Mandatory
1
d) 2 TB, 6G hard drive* 653948-001 Mandatory
1
e) 3 TB, 6G hard drive* 653959-001 Mandatory
1
19
Optical drives (9.5 mm, 0.37 in) — —
a) SATA DVD-ROM drive 652296-001 Mandatory
1
b) SATA DVD-RW drive* 652297-001 Mandatory
1
20
SFF drives (6.35 cm, 2.5 in) — —
Hot-plug drives, SATA — —
a) 100 GB, 3G MLC solid state drive* 653965-001 Mandatory
1
b) 200 GB, 3G MLC solid state drive* 653966-001 Mandatory
1
c) 400 GB, 3G MLC solid state drive* 653967-001 Mandatory
1
d) 500 GB, 6G solid state drive* 656107-001 Mandatory
1
e) 1 TB, 6G solid state drive* 656108-001 Mandatory
1
Hot-plug drives, SAS — —
a) 146 GB, 6G hard drive* 653950-001 Mandatory
1
b) 200 GB, 6G SLC solid state drive* 653961-001 Mandatory
1
c) 300 GB, 6G hard drive* 653955-001 Mandatory
1
d) 300 GB, 6G hard drive* 653960-001 Mandatory
1
e) 400 GB, 6G SLC solid state drive* 653962-001 Mandatory
1
f) 450 GB, 6G hard drive*
653956-001
Mandatory
1
g) 500 GB, 6G hard drive* 653953-001 Mandatory
1
h) 600 GB, 6G hard drive* 653957-001 Mandatory
1
i) 800 GB, 6G MLC solid state drive* 653964-001 Mandatory
1
j) 900 GB, 6G hard drive* 653971-001 Mandatory
1
k) 1 TB, 6G hard drive* 653954-001 Mandatory
1
21
Four-bay LFF non-hot-plug drive cage assembly 686648-001 Mandatory
1
22
Four-bay LFF hot-plug drive cage assembly* 686649-001 Mandatory
1
23
Eight-bay SFF hot-plug drive cage assembly 686651-001 Mandatory
1
24
HP 350 W 1U Factory Integrated Power Supply Kit 686679-001 Mandatory
1
25
HP 460 W CS Gold Hot-Plug Power Supply Kit 511777-001 Mandatory
1
26
RPS enablement kit 686677-001 Mandatory
1
a) RPS cage* — —
b) RPS backplane module — —
d) Power supply blank* — —
27
Low-profile PCIe riser board option 686675-001 Mandatory
1
28
Full-height PCIe riser board option 686676-001 Mandatory
1
29
FBWC module — —
