HP ProLiant DL320e Setup Guide

Downloading the required files
Download the files listed in Table 2 (page 8).
TIP: The HP Service Pack for ProLiant (SPP) includes the iLO firmware and utilities, OA firmware,
and Agentless Management Service. As an alternative to downloading this large file, you can
download the individual components from the websites listed in Table 2 (page 8).
Table 2 Required files
Your file locationDownload pathDescriptionDone?
HP Service Pack for ProLiant website:
http://www.hp.com/go/spp
HP Service Pack for ProLiant
• Version 2012.08.0 (includes iLO firmware
version 1.10 and OA version 3.60)
• Version 2012.06.0 (B) (includes iLO firmware
version 1.05 and OA version 3.55)
iLO drivers and software website: http://
www.hp.com/support/ilo4
Agentless Management Service installer
1
For more information about AMS, see “Using the
Agentless Management Service” (page 35).
iLO drivers and software website: http://
www.hp.com/support/ilo4
HP ProLiant iLO 3/4 Channel Interface Driver
1
iLO drivers and software website: http://
www.hp.com/support/ilo4
iLO firmware. Version 1.05 or later is required
for remote support registration via iLO 4.
1
HP recommends version 1.10 or later.
OA website: http://www.hp.com/go/oa.
Click Software & Drivers, and then click
the link for your OA option. Select an OS.
OA firmware. Version 3.55 or later is required
for remote support registration via OA.
1
HP recommends version 3.60 or later.
HP Software Depot: http://
h20392.www2.hp.com/portal/swdepot/
HP Insight Remote Support 7.0.5 or later installer
displayProductInfo.do?
productNumber=REMOTESUPPORT
HP SIM website: http://www.hp.com/go/
hpsim
(Optional) HP SIM 7.0 or later installer
Tools for enabling the remote support feature in
iLO 4 (iLO firmware version 1.05 only):
• ActivateErs file: See “Creating the
ActivateErs.xml file” (page 31).
• ActivateErs.xml file.
• CPQLOCFG and HPONCFG: iLO drivers
and software website: http://
www.hp.com/support/ilo4
• HP Lights-Out Configuration Utility
(CPQLOCFG).
1
• Sample Perl script package: ftp://
ftp.hp.com/pub/softlib2/software1/
• HP Lights-Out Online Configuration Utility
(HPONCFG)
1
pubsw-linux/p391992567/v67927/
linux-LOsamplescripts3.10.0.tgz
• Sample Perl script package
linux-LOsamplescripts3.10.0.tgz
1
Available in the SPP or as a standalone file.
8 Prerequisites

HP ProLiant DL320e Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor code	SR0PH
Processor cache	8 MB
Processor cores	4
Processor model	E3-1220V2
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Motherboard chipset	Intel® C204
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal Design Power (TDP)	69 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	- \
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	12 TB
Number of HDDs installed	0
Memory slots	4x DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Graphics card	G200
Graphics card family	Matrox
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Power supply	350 W
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	65734
Intel TSX-NI version	0.00
Intel Identity Protection Technology version	1.00
On-board graphics card model	Not available

Weight and Dimensions

Depth	750 mm
Width	434.6 mm
Height	43.2 mm
