17 NVMe port 5A
18 Front I/O connector
19 Fan connector 6
20 Graphics card power connector 1
21 Fan connector 5
22 Not for use in this server
23 TPM connector
24 Fan connector 4
25 Fan connector 3
26 NVMe port 3A
27 NVMe port 1A
28 Fan connector 2
29 NVMe port 2A
30 Not for use in this server
31 Fan connector 1
32 Type-a modular storage controller slot
33 Drive backplane power connector 3
34 Drive backplane power connector 2
35 Chassis intrusion detection switch connector
36 Drive backplane power connector 1
ItemItem DescriptionDescription
