HP ProLiant DL360 Generation 5 (G5) - Page 34

Mirrored memory FBDIMMs configuration requirements (in addition to general configuration requirements):
Banks A and B must be fully populated.
Bank A and bank B must contain FBDIMMs with identical part numbers. If installed, bank C and bank D must also contain
FBDIMMs with identical part numbers.
When using mirrored memory mode, FBDIMMs must be populated as specified in the following table:
Configuration
ConfigurationConfiguration
Configuration Bank A
Bank ABank A
Bank A
1A and 3A
1A and 3A1A and 3A
1A and 3A
Bank B
Bank BBank B
Bank B
5B and 7B
5B and 7B5B and 7B
5B and 7B
Bank C
Bank CBank C
Bank C
2C and 4C
2C and 4C2C and 4C
2C and 4C
Bank D
Bank DBank D
Bank D
6D and 8D
6D and 8D6D and 8D
6D and 8D
1 X X - -
2 X X X X
QuickSpecs
HP ProLiant DL360 Generation 5 (G5)
HP ProLiant DL360 Generation 5 (G5)HP ProLiant DL360 Generation 5 (G5)
HP ProLiant DL360 Generation 5 (G5)
Memory
DA - 12476 North America — Version 27 — September 10, 2007 Page 34
