Cable part numberCable part number ColorColor FromFrom ToTo
P55347-001 Orange Box 2 ports 1–2 x8 SlimSAS ports 5–6 (from
bottom to top) on the processor
mezzanine board
Air cooling configuration:
P55346-001
Liquid cooling configuration:
P61772-001
Blue Box 2 ports 3–4 x8 SlimSAS ports 5–6 (from
bottom to top) on the system
board
Option kit: P55316-B21
Option kit: P61770-B21
When box 1 is the 8 SFF drive cage
1
1
2
1
2
