Hardware options installation 35
7.
Open the heatsink retaining bracket, and then remove the blank, if present.
CAUTION: The pins on the processor socket are very fragile. Any damage to them may require
replacing the system board.
8. Open each of the processor locking levers in the order indicated, and then open the processor retaining
bracket.
