Removal and replacement procedures 49
2.
Close the heatsink locking levers.
3. Connect the heatsink fan cable to the system board.
4. Install the access panel.
5. Do one of the following:
o Close or install the tower bezel, as needed.
o Slide the server back into the rack.
6. Power up the server.
IMPORTANT: Be sure the processor remains inside the processor installation tool.
7. If the processor has separated from the installation tool, carefully re-insert the processor in the tool.
8. Align the processor installation tool with the socket, and then install the spare processor.
