Functional specifications
Table A-1 HP Scitex UV pigment ink supplies
Printheads Two printheads per color: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta. White ink option
replaces Light Cyan and Light Magenta with White.
Ink cartridges Cartridges containing 3 liters of ink: Cyan (CH216A), Magenta (CH217A), Yellow (CH218A), Black
(CH219A), Light Cyan (CH220A), Light Magenta (CH221A).
Cartridges containing 2 liters of ink: White (CQ123A)
Table A-2 Media sizes
Minimum Maximum (FB550) Maximum (FB750)
Media thickness 0.127 mm (0.005 in) 64 mm (2.5 in) 64 mm (2.5 in)
Sheet size with standard input
and output tables
Width: 15 cm (6 in) Length: 1.2 m (48 in)
Width: 1.6 m (64 in)
1.2 m (48 in)
2.5 m (98 in)
Sheet size with standard tables
and optional accessory
extension tables
Length: 22 cm (8.5 in)
Width: 15 cm (6 in)
Length: 3 m (120 in)
Width: 1.6 m (64 in)
Length: 3 m (120 in)
2.5 m (98 in)
Maximum sheet-fed media
weight
N/A 68 kg (150 lb) 68 kg (150 lb)
Sheet flatness Perfectly flat ±0.5 mm (0.02 in) ±0.5 mm (0.02 in)
Roll width 15 cm (6 in) 164 cm (64.5 in) 250 cm (98.4 cm)
Roll diameter N/A 23 cm (9 in) diameter on 7.6 cm
(3 in) core
23 cm (9 in) diameter on 7.6 cm
(3 in) core
Roll weight N/A 82 kg (180 lb) 82 kg (180 lb)
Roll length (with optional
table-top roll holder)
N/A 10 m (33 ft) 10 m (33 ft)
Table A-3 Functional specifications
Print resolutions RIP supports print modes that include resolutions of 1200×600, 600×600, and 600×300 dpi
Minimum margins Set by the RIP, can be set to 0 (edge-to-edge) on rigid and roll-fed media
Technology UV curable inkjet
UV energy source Dual shuttered UV lamps
Ink drop Variable size
Printheads 12
Cleaning solution HP UV Printhead Flush, 1-liter bottle
Within California: Methyl Acetate (CAS# 79-20-9).
104 Appendix A Specifications ENWW
