Table A-5 Printer power specifications (continued)
Required electrical circuit (North America/
Japan)
200–240 VAC, 20 Amps, 60 Hz, single phase, with NEMA L6-20R locking wall receptacle
Required power cord The printer can use any of the following 4.5 m (14.8 ft) power cords:
●
USA: HP part number 8120–6903
●
Europe: HP part number 8120–6899
●
Cord without connector to electric outlet (for use with customer-supplied
connector): HP part number 8120–6895
Optional auxiliary power for ink system
vacuum
When configured as shipped, if the power cord to the printer is removed, power to the
ink system vacuum is removed. If the printer standby power switch is switched off, but
the power cord is not removed, power to the vacuum is preserved. The ink system
vacuum maintains the negative pressure required for printing operation and prevents
ink dripping from the printheads when the printer is idle.
You can preserve power to the ink system vacuum during power outages by connecting
the supplied power cord (length: 137 cm (4.5 ft)) from the auxiliary power connection
(below the ink box racks) to one of the following:
●
Wall outlet — 100–240 VAC, 50/60 Hz, provides temporary power to the vacuum
system when it is necessary to remove power from the printer for service.
●
UPS — Customer-supplied uninterruptable power supply, output 100–240 VAC,
50/60 Hz, minimum of 15 watts of power, provides battery backup to the vacuum
system in the event of a power failure. UPS is connected to the electric wall outlet.
106 Appendix A Specifications ENWW
