2 Tools — Displays the Tools menu. See Tools menu on page 43 for details.
3 Settings — Enables you to enable printer options and adjust various warning timers. See Settings menu on page 44
for details.
4 Language Selection — Switches the control panel language.Language Selection on page 44 for details.
5 System Information — Displays several pages of status information for diagnostic and support purposes.
6 License — Displays the printer software license agreement.
Tools menu
These are less-frequently used functions such as User Diagnostics that enable the operator to diagnose a
problem, Service Printer functions for use by authorized technicians, and the ability to Print Menus (the
entire menu structure) for reference.
User Cleaning and Maintenance
For detailed instructions, see User cleaning on page 74.
●
Maintenance Reminders — Displays a list of scheduled maintenance tasks, the intervals in number of
hours of printing for each task, and the elapsed printing time since the task was last performed.
User Diagnostics
User Diagnostics presents an interactive troubleshooting program to diagnose problems before calling
technical support. It walks you through a series of tests and checks for certain printer functions. The printer
asks you to make observations or run simple tests to help it diagnose problems and suggest corrective
actions. It has the following sections:
●
Carriage Motion
●
Rail Motion
●
Calibration
●
Verify H2H Y Alignment
●
Print Quality
●
Service Station
●
UV System
●
Vacuum Pressure
●
Hard Drive
●
LVDS
●
Print Diagnostic Plot — Prints a pre-RIPed job for troubleshooting.
●
Warnings and Actions List — Table of all actions and warnings with cause and recovery
ENWW
System page 43
