Schedule of tasks
The parts and supplies required for these procedures may be purchased as a kit (HP product number
L1Q41-60034). Consistent and proper use of this kit will contribute to optimal printer performance, extend
lamp and printhead life, reduce the number of service calls, increase image quality, and reduce the potential
for output artifacts.
Follow the cleaning schedule or clean as needed (depending on frequency of use and amount of dust and
airflow around the printer). The printer displays maintenance reminders on the control panel according to
this schedule or actual in-service time, as appropriate. A summary of all service intervals can be seen at
System> Tools> User Cleaning and Maintenance .
Table 10-1 Schedule of cleaning tasks
Task Frequency (hours) Required tools
CMYKcm CMYKW
Clean and lubricate rail strips on page 77
40 20
Oiled cloth kit
One or two lint-free cleaning cloths
Cleaning fluid
Clean the carriage encoder strip on page 78
40 20
One lint-free cleaning cloth
Cleaning fluid
Clean the printheads on page 79
40 20
Three lint-free cleaning cloths
One pair of gloves
Cleaning fluid
Clean the carriage home sensor on page 81
80
Long-stick swab
Cleaning fluid
Clean the service-station wiper rails on page 82
80 40
One grease pack
One pair of gloves
One cotton swab
Cleaning fluid
Clean the service-station wiper on page 83
80 40
One lint-free cloth
One pair of gloves
Cleaning fluid
Clean the carriage wheels on page 84
40
Three long-stick swabs
Cleaning fluid
Vacuum the bottom of the carriage on page 87 80
Replace the UV lamp filters on page 88 250 Lamp filter kit
Clean the electronics box filters on page 89 250 Vacuum cleaner
Replace the service station wiper on page 90
250
Wiper blade
Phillips screwdriver
ENWW Schedule of tasks 75
