2. Insert a thin, plastic tool (2) under the left side of the wireless antenna transceiver and detach the
transceiver (3) from the display panel assembly. (The wireless antenna transceiver is attached to
the display panel assembly with double-sided adhesive.)
3. Disconnect the GPS antenna cable (1) from the system board.
NOTE: The GPS antenna cable must be unsoldered from the system board.
Removal and replacement procedures
19
