20" LCD Color Monitor HP W2007&W2007v
43
Remove the
main frame
1.Remove the
screws
marked in red
to remove the
main board,
power baord,
2.Disconnect
the connector
and remove
the power
board and
main board.
The end
The machine
disconnect
freely
