HP Workstation z400

400 600 800
Lift the side access panel
handle
, and remove the side
access panel
2
Lift the side access panel
handle
, and remove the side
access panel
2
Lift the side access panel
handle
, and remove the side
access panel
2
4. Remove the expansion card support as shown in the following illustrations, if applicable.
400 800
Remove the card support screws , and then
lift the expansion card support from the chassis
2
.
Lift the release tab , and then lift the expansion
card support handle
2
to remove the expansion
card support.
5. Remove the memory and system fans as shown in the following illustrations, if applicable.
40 Chapter 6 Preparing for component installation ENWW
