**SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,
provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please
visit
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf
for
RAID capabilities with Linux.
Form Factor
Form FactorForm Factor
Form Factor
Rackable Minitower
Color
ColorColor
Color
Black/Silver
I/O Slots
I/O SlotsI/O Slots
I/O Slots
(see system
board section for more
details)
2 PCI Express Gen2 x16 slots (full-length, full-height)
1 PCI Express Gen2 x8 slot - with x8 connectors (full-length, full-height)
1 PCI Express Gen1 x8 slot - with x8 connectors (full-length, full-height)
2 PCI 32bit/33MHz slot, (full-length, full-height)
The PCIe x8 connectors are open ended, allowing a PCIe x16 card to be seated in the slot.
Bays
BaysBays
Bays
(see storage section
for more details)
Total Bays = 4
Internal Bays
Internal BaysInternal Bays
Internal Bays
2 internal 3.5" bays (with acoustic dampening rail assemblies)
External Bays
External BaysExternal Bays
External Bays
2 external 5.25" bays
(3rd & 4th HDDs occupy one external bay)
Front I/O
Front I/OFront I/O
Front I/O
3 USB 2.0, 1 Headphone Out, 1 Microphone In, and 1 IEEE 1394a
(For front 1394a port to function, optional 1394 card must be installed.)
Rear I/O
Rear I/ORear I/O
Rear I/O
6 USB 2.0
1 RJ-45 to integrated Gigabit LAN
2 legacy PS/2
1 Audio Line In, 1 Audio Line Out, 1 Microphone In; audio ports can be retasked to function as line in,
line out, microphone, or headphone.
Serial supported with optional rear bulkhead adapter.
Internal USB
Internal USBInternal USB
Internal USB
3 USB 2.0 headers
Chassis Dimensions
Chassis DimensionsChassis Dimensions
Chassis Dimensions
(W x
D x H)
17.5 x 6.5 x 17.3 in (44.51 x 16.53 x 44 cm)
Weight
WeightWeight
Weight
Exact weights depend upon configuration
Minimum config – 33.0 lb (15.0 kg)
Typical config – 37.4 lb (16.9 kg)
Maximum config – 43.3 lb (19.6 kg)
(Maximum shipping weight – 52.0 lb / 23.6 kg)
Temperature
TemperatureTemperature
Temperature
Operating:
40° to 95°F (5° to 35°C)
Non-operating
–40° to 140° F (–40° to 60° C)
Humidity
HumidityHumidity
Humidity
Operating:
8% to 85%
Non-operating
8% to 90%
Maximum Altitude
Maximum AltitudeMaximum Altitude
Maximum Altitude
(non-
pressurized)
Operating:
10,000 feet; 3,000 m
Non-operating
30,000 feet; 9,100 m
Power Supply
Power SupplyPower Supply
Power Supply
650W 85% (80PLUS Bronze) Efficient wide-ranging, active Power Factor Correction, with tool-free &
cable-free connection
Interfaces Supported
Interfaces SupportedInterfaces Supported
Interfaces Supported
6-channel SATA 3.0 Gb/s Interface (6 Serial-ATA connectors on the motherboard, 4 channels are eSATA
configurable for use with eSATA CTO/AMO Kit)
SAS interface supported with optional LSI 3041E 4-port SAS/SATA PCIe card.
1 Floppy interface (1 Floppy connector), USB 2.0
Hard Drive Controllers
Hard Drive ControllersHard Drive Controllers
Hard Drive Controllers
Supported
SupportedSupported
Supported
SATA and SAS controllers
QuickSpecs
HP Z600 Workstation
HP Z600 WorkstationHP Z600 Workstation
HP Z600 Workstation
Overview
DA - 13277 North America — Version 2 — April 13, 2009
Page 4
