HP Z820

LSI MegaRAID® 9260-8i
SAS 6Gb/s ROC RAID Card
and iBBU07 Battery
Backup Unit
PCI Bus PCI-Express (Gen2) V2.0 x8 lanes
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 5, and 6
RAID spans 10, 50 and 60
PCI Data Burst Transfer
Rate
Up to 4GB/s
PCI Card Type Low profile, single PCIe slot design with full height bracket.
The optional iBBU07 Battery Backup unit mounts on the controller card and
the assembly remains within a single PCIe slot width.
PCI Voltage +3.3V Add-in Card
PCI Power 12.5 Watts
Certification Level PCI-Express 2.0
IO Bus Eight 3 Gb/s and 6Gb/s compatible SAS/SATA ports
Internal Connectors Two SAS SFF8087 x4
External Connectors None
Maximum Number of SCSI
Devices
32.
NOTE: HP Workstations do not support this many internal drives.
LED Indicators Connector LEDs indicate whether the internal connector is active for ports 0-3
and 4-7
LSI 9270-8i SAS 6Gb/s ROC
RAID Card and iBBU9
Battery Backup Unit
PCI Bus x8 lane PCIe 3.0 compliant
RAID Levels RAID 0, 1, 5, and 6
RAID spans 10, 50 and 60
PCI Card Type Low profile, single PCIe slot design with full height bracket.
PCI Voltage +3.3V Add-in Card
PCI Power +3.3V, +12V
Certification Level PCI-Express 3.0
IO Bus Eight 6Gb/s and 3Gb/s compatible SAS/SATA ports
Internal Connectors Two SAS SFF8087 x4 (Mini-SAS)
External Connectors None
Maximum Number of SCSI
Devices
Up to 128 SAS and/or SATA hard drives and SSDs
Note: HP Workstations do not support this many internal drives.
LED Indicators Heartbeat LED on card
QuickSpecs
HP Z820 Workstation
Technical Specifications - Hard Drive Controllers
DA - 14264 North America — Version 36 — December 1, 2013 Page 48
