Blitz
™
No. 1200CMB
108
1200CMBaCDC Parts Listing
# Description Stock #
1. Pivot Arm Complete CM-1024X
2. Cutter Nut CM-1039MA
3. Cutter Sold Separately
4. Cutter Head
Assembly Complete CM-1053X
5. Spring CM-1079
6. Washer CM-50100
7. Pivot Pin CM-1043
8. Hex Nut CM-50157
9. Belt CM-1083MA
10. Cap Screw CM-50158
11. Angle Index Pin CM-1042
12. Hex Nut CM-50148
13. Toggle Switch ACDC-SW
14. Crank Bearing CM-1045
15. Set Screw 9100-11
16. Motor Pulley CM-1060B
17. Washer CM-50149
18. Motor (12 V DC) DC-MOTOR
19. Cap Screw CM-50167
20. Washer CM-50167-1
21. Motor Mounting Bracket CM-1040MA
22. Set Screw CM-50165
23. Cotter Pin CM-62CP
24. Retaining Ring CM-50183
25. Cap Screw CM-50134
26. Lateral Crank Complete CM-1044X
27. Lateral Rack Bracket CM-1030
# Description Stock #
28. Pivot Arm Shaft CM-1034
29. Rubber Foot CM-50133
30. Dogging Screw CM-1016
31. Teflon Washer CM-1086
32. Washer CM-50100
33. Spring CM-1098
34. Retaining Ring CM-50126
35. Depth Crank Complete CM-1026X
36. Depth Crank Shaft CM-1031B
37. Transformer for ACDC ACDC-TRANS
39. Set Screw CM-50112
38. Dial Plate Complete CM-1050
39. Lateral Feed Shaft CM-1047B
40. Screw CM-50154
41. Lens CM-1012
42. Brush TYX-3
43. Screw CM-50134
44. Belt Guard CM-1014B
45. Brush Guard CM-1096B
46. Screw CM-50177
47. Cap Screw 9100-28
48. Washer CM-50130
49. Base CM-1255MAO
50. Rectifier ACDC-RECT
51. Cap Screw CM-50167
52. AC Cord CM-1294MAO
53. DC-Cord DC-CABLE
54. Motor Support CM-50186
55. Motor Support Screws (2) CM-50188
