Blitz
™
No. 1200CMB
111
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
13
030702
22
23
24
25
26
1200CM/1200CMB PIVOT ARM ASSEMBLY
# Description
Stock #
1. Easy Grip Wing Nut EGN-1
2. Ball Bearing Washer BBW-2
3. Top Jaw CM-1056MA
4. Spring CM-1293MA
5. Stud CM-1019MA
6. Ball Bearing CM-50108
7. Set Screw CM-50110
8. Bottom Jaw (factory installation recommended) CM-1055MA
9. Tip Stop CM-1054MA
10. Spring CM-1090MA
11. Set Screw CM-50139
12. Eccentric Shaft CM-1041
13. Set Screw CM-50109
14. Set Screw CM-50112
15. & 16 Turn Bar & Shoulder Gauge CMB-FG
17. Retaining Ring CM-50105
18. 2-56 Screw MAX-92
19. Shoulder Gauge Wire Assembly MAX-90
20. Shoulder Gauge Micro Switch Bracket MAX-91
21. 6-32 Set Screw MAX-89
22. Specialty Tip Stop - Safe Deposit Keys RT-SD
23. Horseshoe Tip Stop CM-1054R
24. Specialty Tip Stop - Safe Deposit Keys HT-SD
25. Specialty Tip Stop - L & F Safe Deposit Box Keys HT-125
26. Specialty Tip Stop - L & F Safe Deposit Box Keys HT-625
