Blitz
™
No. 1200CMB
20
No. CMB-FG
Shoulder Gauge
Place key blank in the jaw with the shoulder touching the left hand edge of
shoulder gauge. Flip the shoulder gauge down before turning on the motor.
The space dimension can be significantly affected by any damage incurred to
the shoulder gauge.
Damage to the shoulder gauge can occur when it comes in contact with the
cutter, or when undue pressure is used when gauging against the key’s shoulder.
standard cylInder Key
wIth shoulder gaugIng usIng Jaw a.
(Example: Schlage, Card No. C45)
sectIon 3.1
