HPC Blitz 1200CMB - Page 5

Blitz
™
No. 1200CMB
4 4
CM-1096B (brush guard)
CM-1080MA (motor)
CM-1014B (belt guard)
CM-1043 (pivot pin)
CM-1053X (cutter head assembly)
EGN-1 (Easy Grip Wing Nut)
CM-1012 (HPC lens)
CM-1056MA (key vise)
CM-1055MA (key vise base)
CM-1041 (eccentric shaft)
CM-1044X (lateral crank assy.)
CM-1034 (pivot arm shaft)
CM-1054MA (tip gauge)
CM-1045 (depth crank bearing)
CM-1026X (depth crank assy.)
CMB-FG
(Shoulder Gauge Assembly)
CM-1042 (angle index pin)
CM-1083MA (motor belt)
TYX-3 (Softie
™
brush)
9150-29 (brush nut)
CM-1060B (motor pulley)
CM-1039MA
(cutter shaft nut)
CM-1099MA
(toggle switch)
Cutter
(wide selection available)
PARTS DESIGNATION CHART FOR THE
1200CMB CODE MACHINE
1200C-SGS
(Shoulder Gauge Safety Switch)
EFLIP-1200 (Easy Flip)
