HPC Blitz 1200CMB - Shoulder Gauging: Space Indicator Offset Correction

Blitz
™
No. 1200CMB
94
Rotate lateral crank to position the key with the most easily seen
cut carefully centered beneath the cutter as shown. Rotate the
depth crank until the cutter is fairly deep within the cut. If space
indicator needle is centered over the corresponding space mark
the space adjustment is correct. Go no further.
