HPE MSA 2050

1
2
3
4
5
6
7
8
1. MSA 2050 array controller 2. MSA 2050 disk enclosure
3. MSA 2050 disk enclosure 4. MSA 2050 disk enclosure
5. MSA 2050 disk enclosure 6. MSA 2050 disk enclosure
7. MSA 2050 disk enclosure 8. MSA 2050 disk enclosure
Connecting the MSA 2050 array to expansion disk enclosures 11
