HPE ProLiant DL320 Gen11

To Next Page

To Previous Page

ItemItem DescriptionDescription

1 Boot device cage

2 M.2 slots

3 Boot device

carriers

HPE NS204i-u Boot Device HPE NS204i-u Boot Device LED definitionsLED definitions

HPE ProLiant DL320 Gen11 Server Maintenance and Service Guide 210
