11. Disconnect the signal and power cables from the boot device.
12. Remove the boot device bracket:
a. Remove the bracket screw (callout 1).
b. Remove the bracket from the boot device (callout 2).
13. Remove the boot device carrier:
a. Press and hold the carrier latch (callout 1).
b. Pivot the latch to open (callouts 2).
c. Slide the carrier out from the boot device cage (callout 3).
