ItemItem DescriptionDescription
1 Guide pins
2 DIMM guards
3 Cable
guards
If a midtray is installed, there will be no cable guards.
Cabling diagramsCabling diagrams
Observe the following:
Before cabling components, see the cabling guidelines.
Use the cable part number or search feature to find your diagram.
Component cablingComponent cabling Cable part numberCable part number
Front SFF drive power cabling
P57198-001
P58023-001
P57209-001
1
1
