3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5. Do one of the following:
Extend the server from the rack .
Remove the server from the rack .
6. Remove the access panel.
7. Do one of the following:
a. Remove the air baffle.
b. Remove the midplane drive cage .
8. If installed, remove the cable guards .
9. Remove the DIMM guard.
