HPRT HT800 Quick Start Guide

-3-
Paper Loading Ribbon Loading
-4-
Note: Please refer to windows driver installaon in HT800/HT830 User Manual.
！
1.Pull and li the cover.
2.Pull the roll holders open and place the roll between them, then press
down the locking tab.
3.Pass the labels through label guides and adjust label guides to adapt to
the label width.
1.Install the ribbon module.
2.Insert the le part of supply spindle
and then the right part spindle.
Ribbon Supply Spindle
Ribbon Rewind Spindle
Sckup
3.Press down the printer mechanism.
6.Press down the mechanism and
close the cover.
4.Insert the le part of rewind spindle
and then the right part.
5.Wind the core 2~3 circles unl the
ribbon is pulled ghtly.

HPRT HT800 Specifications

General

Brand	HPRT
Model	HT800
Category	Barcode Reader
Language	English
