22 SECURIO AF 300 11/2014
english
10 Technical data
* The maximum number of sheets (DIN A4, 70 g/m² or 80 g/m²), fed lengthways, which can be cut in one cycle. The
performance data is determined when the motor is cold and the cutting device is freshly oiled. A weaker mains voltage
or a different mains frequency to the one specifi ed could result in less sheet capacity and increased noise during op-
eration. The sheet capacity can vary depending on the structure and properties of the paper and on the way it enters.
Cutting type Cross cut
Cut size (mm) 4.5 x 30 1.9 x 15 0.78 x 11
Security level DIN 66399 P-4 / O-3 / T-4 / E-3
F-1
P-5 / T-5 / E-4 / F-2 P-6 / F-3
Cutting capacity* (sheets), A4 70 g/m
2
80 g/m
2
14 - 16
12 - 14
9 - 11
8 - 10
7
6
Weight 20.6 kg 20.4 kg 20.5 kg
Cutting speed 65 mm/s
Intake width 240 mm
Power supply 230 V, 50 Hz 110 V - 120 V, 60 Hz 220 V, 60 Hz
Power consumption with max. number of sheets 500 W
Energy consumption in standby mode < 2 Wh
Operating mode Continuous operation
Ambient conditions in operation:
Temperature
Relative humidity
Height above sea-level (MSL)
-10 °C to +25 °C
max. 90 %, without condensation
max. 2,000 m
Size W x D x H (mm) 395 x 435 x 837
Shredded material container volume 34 l
This document shredder meets the applicable harmonisa on legisla on of the European Union:
• Low Voltage direc ve 2006/95/EU
• EMC direc ve 2004/108/EU
• RoHS direc ve 2011/65/EU
The EU declara on of conformity can be requested from the manufacturer.
