Figure 4-16 Connecting an optical cable
When you use an SFP+ cable:
1. Remove the old SFP+ cable.
Gently push the cable connector inwards and pull the latch out to remove the SFP+
cable. See Figure 4-17.
NOTICE
Do not directly pull out the latch.
2288H V5 Server
User Guide
4 Setup
Issue 04 (2018-09-04) Copyright © Huawei Technologies Co., Ltd. 84
