AC6605 Access Controller
Dual-Link Backup White Paper
1 Dual-Link Backup
Issue 01 (2012-05-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
36
gateway-list 19.19.19.2
network 19.19.19.0 mask 255.255.255.0
excluded-ip-address 19.19.19.1
excluded-ip-address 19.19.19.3 19.19.19.100
option 43 ascii HuaweiAC-19.19.19.1,19.19.19.2
interface Vlanif3010
ip address 19.19.19.2 255.255.255.0
dhcp select interface
#
interface XGigabitEthernet0/0/1
port link-type trunk
port trunk allow-pass vlan 3010 3931
#
wlan
wlan ac source interface Vlanif3010
wlan ac protect enable protect-ac 19.19.19.1 priority 7
service-set name set1 id 1
forward-mode tunnel
service-vlan 3931
#
return
# Wired-side configuration file of AC2
#
sysname lsw_AC1
#
vlan batch 3010 3931
#
interface GigabitEthernet0/0/1
port link-type trunk
port trunk pvid vlan 3010
port trunk allow-pass vlan 3010
#
interface XGigabitEthernet0/0/27
port link-type trunk
port trunk allow-pass vlan 3010 3931
#
return
Configuration file of the aggregation switch
#
sysname LSW
#
vlan batch 3010 3931
#
interface Vlanif3931
ip address 30.30.30.5 255.255.255.0
#
interface GigabitEthernet0/0/1
description connect to active AC
port link-type trunk
port trunk pvid vlan 3010
port trunk allow-pass vlan 3010
#
interface GigabitEthernet0/0/2
