Figure 9-3 MSTI
Root
VLAN
10&20&30
VLAN10&20
VLAN 20&30
VLAN
10&30
VLAN30
VLAN
10&30
VLAN20
VLAN 10
MST Region
Root
MSTI
corresponding to
VLAN 10
Root
MSTI
corresponding to
VLAN 20
MSTI
corresponding to
VLAN 30
MSTI links
MSTI links blocked by the protocol
MSTIs are independent of each other. An MSTI can correspond to one or more VLANs,
but a VLAN can be mapped to only one MSTI.
