Figure 2-14 RH8100 V3 components (front view)
1 Chassis 2 DVD drive+LCD module
3 Compute module 4 Front I/O module (the FM-A
is used as an example in the
gure)
RH8100 V3 Server
User Guide 2 About the RH8100 V3
Issue 30 (2019-12-19) Copyright © Huawei Technologies Co., Ltd. 39
