Context
Table 12-6 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID: 12
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
Networking data IP address of the MGC server: 200.200.200.200/24
Port ID of the MGC server: 2944
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Set the profile name to ftto_voip and do not limit the upstream and downstream rates.
Set the priority to 5 and packets are scheduled according to the priority carried.
Run the display traffic table ip command to query existing traffic profiles in the
system. If the existing traffic profiles in the system do not meet the requirements, run
the traffic table ip command to add a traffic profile.
huawei(config)#traffic table ip name ftto_voip cir off priority 5 priority-
policy
local-setting
2. Configure the mapping between a GEM port and a VLAN. Create a service VLAN
and a service flow.
Table 12-7 Scenario plan
Scenario VLAN Plan VLAN Translation Policy
Scenario 1 Single VLAN tag
l S-VLAN ID: 300
l S-VLAN type: smart
l S-VLAN attribute:
common
l C-VLAN ID: 300
ONU: Configure a VLAN
for all ONUs and add the
same C-VLAN tag to
packets. All ONUs are in the
same C-VLAN.
OLT: The OLT transparently
transmits VLAN tags (the C-
VLAN is the same as the
planned S-VLAN).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1108
