Indicator State Description
25GE
optical
port
Transmission rate
indicator
● Steady green: The data transmission
rate is 25 Gbit/s.
● Steady yellow: The data transmission
rate is 10 Gbit/s.
● O: The network port is not connected.
Connection status
indicator/Data
transmission status
indicator
● Steady green: The network port is
properly connected.
● Blinking green: Data is being
transmitted.
● O: The network port is not connected.
PSU indicator ● Steady green: The power input and
output are normal.
● Steady orange: The input is normal, but
no power output is supplied due to
overheat protection, overcurrent
protection, short circuit protection,
output overvoltage protection, or some
component failures.
● Blinking green at 1 Hz:
– The input is normal, the server is
standby.
– The input is overvoltage or
undervoltage. For details, see
TaiShan Rack Server iBMC Alarm
Handling .
● Blinking green at 4 Hz: under online
PSU
rmware upgrade.
● O: No power is supplied.
2.5 FlexIO Cards
For details about FlexIO cards supported by the server, see the Computing
Product Compatibility Checker. For details about the specications and features
of each FlexIO card, see the corresponding user guide.
The following
gures show the indicators on the FlexIO cards.
