TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
Copyright © Huawei Technologies Co., Ltd.
Table 2-1 Configurations
Temperature
control unit (TCU)
Equipment compartment: direct
ventilation
Battery compartment: thermoelectric
cooler (TEC)
Equipment compartment: HXC70S
heat exchanger
Battery compartment: TEC
Space for customer
equipment
220/380 V AC
three-phase,
four-wire input
system, compatible
with 220 V AC
single-phase input
system
220/380 V AC
three-phase,
four-wire input
system, compatible
with 220 V AC
single-phase input
system
One 3-pole 63 A
circuit breaker
One 2-pole 100 A
circuit breaker
One 3-pole 63 A
circuit breaker
One 2-pole 100 A
circuit breaker
(Optional) AC
output circuit
breaker
One 2-pole 10 A circuit breaker and one 3-pole maintenance socket protected by an 10 A
electric residual current device (RCD).
Battery low voltage disconnection (BLVD): two 1-pole 10 A circuit breakers and
four 1-pole 16 A circuit breakers
Load low voltage disconnection (LLVD): one 1-pole 100 A circuit breaker, one
1-pole 63 A circuit breaker, and four 1-pole 32 A circuit breakers
Battery route: two 1-pole 125 A circuit breakers
A maximum of four R4850G2s or R4830G2s can be configured.
Mandatory: one battery temperature sensor, one ambient temperature sensor in the
equipment compartment, and one door status sensor
Optional: one smoke sensor, one ambient temperature and humidity sensor, and one
water sensor.
(Optional)
Intelligent electric
meter
One intelligent electric meter and one current transformer
(Optional)
Bluetooth door lock
One electric door lock and one Bluetooth controller
The battery compartment with two layers supports a maximum of two 12 V, 180 Ah
battery strings.
