1.
Apply height adjustment and moving label (46) to front of pole as shown.
2.
A.While holding handle, remove pin (26).
B. Move elevator up or down to desired height.
C. Replace pin (26) full length to lock system at desired height.
SECTION C: APPLY HEIGHT AND MOVING LABEL & HEIGHT ADJUSTMENT
46
10 ft.
(3.05 m)
26
A.
B.
C.
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT
IN SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
Peel protective film from
surface of acrylic
backboard prior to use.
NOTE:
DO NOT ALLOW
CHILDREN TO
ADJUST HEIGHT.
WARNING!
