Humidity Source UH-300 - Mist Generator Replacement

How to replace the mist generator:
1. Remove the 12 screws at top.
2. Open the acrylic cover. Protect the gasket.
3. Unscrew the 2 nuts on the mist generator.
4. Remove the mist generator cables from the
converter.
(Note the position of the each cable colors : White
& Red)
5. Connect the new mist generator cables to the
converter using the same colors as above.
Refer to the picture [How to connect the cables]
6. Reinstall cover.
1.
2.
3.
4.
5.
