Hunter Saturn 90052 - New Construction: Suspended Between Joists Installation (Final Steps)

41718-01 01/28/2008
10
B27
E1
Go to step
on page 17
to attach grille.
B22
H
Connect wiring from the motor to the wiring cover plate.
H
B23
Reinstall the motor by inserting the tabs and pushing up into
position. Make sure the wires are not pinched
between the motor and the housing.
B25
Turn on the power source.
ON
OFF
B26
Test the motor. If the motor does not run,
check the plug connection.
B24
I
Secure the motor by tightening the 2 screws.
