Hunter Saturn 90052 - Existing Construction: Accessible From Below Installation (Final Steps)

41718-01 01/28/2008
17
ON
OFF
D22
D23
E1
Go to step
on page 17
to attach grille.
D21
Test the motor. If the motor does not run,
check the plug connection.
Turn on the power source.
Attaching the Grille
Remove the thumbscrews.
Connect wiring harness.
M
E
E1
L
E2
