Hunter Saturn 90052 - New Construction: Attaching to Joist Installation (Final Steps)

41718-01 01/28/2008
7
A19
I
Secure the motor by tightening the 2 screws.
A20
Turn on the power source.
Connect wiring from the motor to the wiring cover plate.
0000
A17
Reinstall the motor by inserting the tabs and pushing up into
position. Make sure the wires are not pinched
between the motor and the housing.
0000
H
A18
ON
OFF
A21
Test the motor. If the motor does not run,
check the plug connection.
A22
E1
Go to step
on page 17
to attach grille.
