Chapter D: Specification
1.0 AC input voltage
1.1 Input over-current protection
The power supply shall incorporate one input fuse on the LINE side for input
over current protection to prevent damage to the power supply and meet
product safety requirements. Fuses should be slow blow type or equivalent to
prevent nuisance trips. AC inrush current shall not cause the AC line fuse to
blow under any conditions.
1.2 Efficiency
This series power supply is high efficiency nearly reach 80% at typical
load.
2.0 DC output voltage regulation
2.1 DC output power distribution
APFC 500 output power distribution
+3.3V&+5V total output don't exceed 130W
Output watt: 400W (continues)
Max. Output Capacity: 500W
Parameter Minimum Normal Maximum
Unit
Vin/Voltage
Vin/Frequency
180
47
100--240
—
265
63
Vrms
Hz
Output Range Min. Nom. Max. Unit
+12V1,2,3,4DC
+5VDC
+3.3VDC
-12VDC
+5VSB
±5%
±5%
±5%
±10%
±5%
+11.4
+4.75
+3.14
-10.80
+4.75
+12.00
+5.00
+3.30
-12.00
+5.00
Volts
Volts
Volts
Volts
Volts
+12.60
+5.25
+3.47
-13.20
+5.25
Output
Max.Load
Min.Load
+3.3V +5V +12V1 +12V2
24.0A 17.0A 16.0A 18.0A
0.5A 0.3A 1.0A 1.0A
-12V
0.5A
0.0A
+5VSB
2.5A
0.0A
APFC 600 output power distribution
+3.3V&+5V total output don't exceed 130W
Output watt: 500W (continues)
Max. Output Capacity: 600W
APFC 700 output power distribution
+3.3V +5V +12V1 +12V2
24.0A 20.0A 18.0A 18.0A
0.5A 0.3A 1.0A 0.8A
-12V
0.5A
0.0A
+5VSB
2.5A
0.01A
+3.3V +5V +12V1 +12V2
25.0A 25.0A 18.0A 18.0A
1.5A 1.0A 0.5A 0.5A
-12V
0.5A
0.0A
+5VSB
3.0A
0.1A
+12V3 +12V4
18.0A 18.0A
1.0A 0.5A
+3.3V&+5V total output don't exceed 140W
Output watt: 600W (continues)
Max. Output Capacity: 700W
Output
Max.Load
Min.Load
Output
Max.Load
Min.Load
Ripple & Noise
+3.3V
+5V
+12V1,2,3,4
-12V
+5VSB
50mVp-p 50mVp-p 50mVp-p120mVp-p120mVp-p
2.2 Output Ripple & Noise
