1-
4
Table 1-1 (continued)
Tracker 2700/2700S Specifications
ELECTRICAL
Access
Channel A & B Shrouded Red Banana jacks
Common Shrouded Black Banana jack
Ch. A and Ch. B scanning interfaces 40 pin IDC connectors (2700S only)
DC Voltage Source Shrouded Blue Banana jack
Display
LCD Color 3.8in 240X320 Pixel
DC Source
Output Resistively coupled
Level 0 to 5VDC
Output Impedance 24Ω
Short Circuit Current 200 mA max
Power Requirements
AC Line Voltage 115VAC/230VAC
Line Frequency 50/60 Hz
Power 40 watts Maximum
Line Protection 400mA Fuse
