IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Service
A highly trained technical service department is maintained by Hurst Performance to answer your
technical questions, provide additional product information and offer various recommendations.
Hurst offers a wide variety of custom T-Handles and knobs that can be sued with this shifter to allow
the driver to tailor the vehicle to his/hers personal liking. See your local retailer of Hurst products for
specific prices.
Technical service calls, correspondence, and warranty questions should be directed to:
Hurst Performance Products
(707) 544-4761
www.Hurst-Shifters.com
TechnicalSupport(707)544‐4761 2 www.HURST‐SHIFTERS.co m
SPEEDOMETER
COUPLING CLAMP
AND HARDWARE
SPEEDOMETER
STOCK BACK-
DRIVE ROD &
LOCKNUT
CONTENTS OF KIT
1. MOUNTING PLATE
2. 5/16-18x1 FLAT HEAD SOCKET
SCREW
3. 5/16-18x1 HEX HEAD CAP SCREW
4. 5/16” SPLIT LOCKWASHER
5. 7/16-14x2 3/4 HEX HEAD CAP SCREW
6. 7/16” SPLIT LOCKWASHER
7. 7/16” FLATWASHER
8. 3/8-16x2 3/4 HEX HEAD CAP SCREW
9. 3/8” INTERNAL/EXTERNAL TOOTH
LOCKWASHER
10. BACK-UP LIGHT SWITCH BRACKET
11. ROD ADJUSTING BUTTOON
12. NYLON BUSHING
13. SPRING CLIP
14. ARM 1ST/REV.
15. ROD 1ST/REV.
16. ARM 2ND/3RD
17. ROD 2ND/3RD
STOCK NUT
STOCK
BACK‐DRIVE
BACK-UP LIGHT SWITCH BRACKET IS
INSTALLED UNDER JAM NUT ON 2ND
GEAR STOP BOLT.
SWITCH IS NOT INCLUDED
