All Products limited to Vehicle Tow Rating, see Vehicle Owners Manual. Visit www.huskytow.com for Warranty Information / Tech Support /
Product Updates. 2021 Keystone Automotive Operations Inc. All Rights Reserved. 05/04/2021-Rev12
Page-9
12. Put a conical tooth washer on the top 3/4” hex bolt followed by a 3/4” nylon lock nut. Put a
3/4” flat washer on the bottom 3/4” hex bolt followed by a 3/4” nylon lock nut. Torque the 3/4”
nylon lock nuts to 380 ft-lbs.
3/4” nylon
lock nut
3/4" flat
washer
13. Insert a spring bar with the rating stamp facing up into the trunnion. Secure with the “D”
retaining pin.
BE SURE THAT THE “D” RETAINING PIN GOES THROUGH HOLE IN THE SPRING BAR.
Spring bar
“D” retaining pin
To Next Page
