SINGLE SWING DOOR
• Swing doors can be installed Left/Right Hand,
Swing In or Swing Out.
• The Picture shows Hinge right Swing Out
(HRSO) door looking from outside of the
cage.
• The opening between the posts for a swing
door installation is equal to Nominal Width –
2 3/8”. (For example for 3’ door the opening
between the post is 36-2 3/8” = 33 5/8”)
Install Transom panel first and anchor the
Transom Panel
Install Transom panel first and anchor the
line posts to the floor ensuring the opening
width at the floor equals the transom width.
• Using 5/16” x 3” Carriage Bolts (3), attach
door and strike bar to the posts.
• Install Cylinder Lock (see page…).
Bar
6
